Roadmachine AMP
THREE
The Roadmachine AMP has hidden power thanks to Mahle's benchmark, ultra-compact hub drive unit, which has a leading power-to-weight ratio. While it looks, handles and performs like a Roadmachine, this e-road bike assists you through the tough parts so you can achieve more. The drive unit’s internal battery can be removed from the TCC Endurance Premium Carbon frameset, and there’s a Premium Carbon D-Shape seatpost and RSM stem. The more affordable AMP has a mechanical shifting, Shimano 105 compact groupset, tubeless-ready XRD-522 wheels and 30mm tires. |
|
Najbliższy sprzedawca przedstawi Ci ofertę.
Obowiązek informacyjny
Administratorem Twoich danych osobowych jest: Taurus Active sp. z o.o. , NIP 6351864367, Regon 524105331 z siedzibą przy ul. Józefa Wieczorka 11, 43-190 Mikołów, zwanym dalej „Administratorem” . Więcej »
Tuned Compliance Concept (TCC) Endurance The most capable version of our TCC technology: take the edge off the roughest roads to push harder and ride further. The ultimate balance between comfort and performance for a ride that is both forgiving and fast. |
Integrated Pedal Assist The seamlessly integrated Mahle X20 drive unit provides 25Nm of sensor-tuned assistance for a natural ride feel, and its smart battery optimizes power delivery, giving you a range of up to 140 Km with 3000 meters of elevation. |
Iconic Silhouette Featuring Roadmachine's renowned geometry to deliver incredibly poised handling, with clean lines and integrated cable routing, maintaining that iconic Roadmachine silouette. |
Tire Versatility Supplied with 28 mm wide tires, the Roadmachine AMP has frame clearance for tires with a measured width of 33mm when installed allowing riders to venture into mixed-terrain riding. |
D-Shape Seatpost The D-Shape compliance post's carbon layup was designed using TCC Endurance technology for tailored comfort. |
Integrated Seat Clamp The seamless and functional integrated seatpost clamp is hidden within the frame. |
Technologia
TCC |
Tuned Compliance ConceptWydajność na wysokim poziomie – sztywność tam, gdzie jest to potrzebne, oraz ugięcie w odpowiednich miejscach. |
Dane techniczne
-
Rama
Premium Carbon
-
Widelec
Roadmachine AMP Premium Carbon with Tuned Compliance Concept Endurance; • Internal Cable Routing; • Flat Mount Disc; • 12x100mm Thru-Axle
-
Korba
Shimano 105 50-34T
-
Kaseta
SHIMANO 105 11-32T
-
Łańcuch
Shimano 105
-
Przerzutka przód
Shimano 105
-
Przerzutka tył
Shimano 105
-
Manetki
Shimano 105
-
Hamulce
SHIMANO 105, RT70 / RT66 (F/R) Rotors (160/160)
-
Kierownica
BMC RAB 02, ergo top shape, compact bend
-
Mostek
BMC RSM
-
Wspornik siodełka
Roadmachine AMP Premium Carbon D-Shaped Seatpost; • 15mm Offset;
-
Biegi
2×11
-
Siodełko
Fizik Taiga
-
Piasty
XRD-522, Ebikemotion
-
Obręcze
XRD-522, Tubeless Ready, 25 mm
-
Opony
Vittoria Rubino Pro, 30mm
-
Rozmiary
47, 51, 54, 56, 58, 61
-
Maks. rozmiar opony
33mm (Measured Width)
Size | 47 | 51 | 54 | 56 | 58 | 61 |
---|---|---|---|---|---|---|
Rider Height CM | <166 | 166-174 | 172-180 | 178-186 | 184-192 | >190 |
Stack MM | 516 | 541 | 562 | 586 | 610 | 644 |
Reach MM (reach) | 374 | 382 | 386 | 390 | 394 | 398 |
Seat Tube MM (st) | 420 | 457 | 500 | 522 | 539 | 573 |
Top Tube MM (tt) | 522 | 532 | 546 | 556 | 568 | 583 |
Head Tube MM (ht) | 112 | 139 | 156 | 181 | 206 | 242 |
Seat Tube Angle (sa) | 74.2 | 74.2 | 74.2 | 74.2 | 74.2 | 74.2 |
Head Angle (ha) | 71.2 | 71.2 | 72 | 72 | 72 | 72 |
Rear Center MM (rc) | 410 | 410 | 410 | 410 | 410 | 410 |
Front Center MM (fc) | 583 | 599 | 597 | 609 | 621 | 635 |
Wheelbase MM (wb) | 982 | 999 | 997 | 1008 | 1020 | 1035 |
BB Drop MM (drop) | 71 | 71 | 71 | 71 | 71 | 71 |
Fork Length MM (fl) | 375 | 375 | 375 | 375 | 375 | 375 |
Fork Rake MM (fr) | 50 | 50 | 45 | 45 | 45 | 45 |
Trail MM (trail) | 63 | 63 | 63 | 63 | 63 | 63 |
Crank Length MM | 170 | 170 | 172.5 | 172.5 | 175 | 175 |
Stem Length MM | 90 | 90 | 100 | 110 | 110 | 120 |
Stem Angle | -12.5 | -12.5 | -12.5 | -12.5 | -12.5 | -12.5 |
Bar Width MM | 400 | 420 | 420 | 420 | 420 | 440 |
Bar Drop MM | 125 | 125 | 125 | 125 | 125 | 125 |
Bar Reach MM | 70 | 70 | 70 | 70 | 70 | 70 |
Post Offset MM | 15 | 15 | 15 | 15 | 15 | 15 |
Standover Height mm | 719 | 750 | 782 | 805 | 825 | 859 |
Seatpost Length MM | 330 | 380 | 380 | 380 | 380 | 430 |
