Kaius 01
THREE
| Kaius is a premium carbon gravel bike built to be your elite race companion for all terrains. The unprecedented carbon layup and gravel-specific geometry ensure the perfect balance of stiffness, lightweight, and compliance for optimal traction on loose surfaces, front-end stability, and unmatched climbing prowess. Harnessing the precision and performance of our renowned leading road technologies, Kaius is a race machine tuned to the gravel wavelength with the engineered Kaius fork, our signature ICS2 stem and conventional bar, TCC Race compliance, compatibility with 1x and 2x drivetrains and up to 44 mm of tire clearance. |
|
Premium Carbon
Kaius 01 Premium Carbon with Aerocore Design ICS Technology
SRAM FORCE 12
SRAM Red eTap AXS HRD, tarcze Centerline X (160/160)
Pirelli Cinturato Gravel H, 40mm
Najbliższy sprzedawca przedstawi Ci ofertę.
Obowiązek informacyjny
Administratorem Twoich danych osobowych jest: Taurus Active sp. z o.o. , NIP 6351864367, Regon 524105331 z siedzibą przy ul. Józefa Wieczorka 11, 43-190 Mikołów, zwanym dalej „Administratorem” . Więcej »
Speed Unbound The innovative premium carbon layup uses ultra high-module fibres for unmatched stiffness resulting in maximum power transfer and minimal weight. Kaius boasts our Tuned Compliance Concept Race Technology for a comfortable ride on rough surfaces and targeted reinforcements protect your frame against the demands of gravel racing. |
Race-ready Gravel Geometry Kaius was built with one purpose: to be fast on gravel roads. That is why we produced a gravel-specific frame with a longer reach shifting the front wheel forward to improve stability and increase traction on loose surfaces. With the shorter stem providing responsive handling, Kaius sports a progressive and race-tuned geometry for evolving riding styles. |
Integrated Cockpit System (ICS) The ICS Carbon Aero cockpit features an advanced design and reduced frontal section to match the performance of our race machines. It also arrives with 360mm top width at the hoods, a 12,5° flare, and 420mm width at the drops to provide excellent control at high speeds. |
Aerocore Design Kaius comes in at the highest level of functional integration with our Aerocore design. This evolved solution integrates the bottle cages into the frame to optimize aerodynamic performance. |
Lightweight Being a race bike, Kaius is not only stiff and comfortable but also lightweight. With a frame weighing only 910g, the fork 400g, a seat post at 160g, and the cockpit clocking in at 315g, we produced a module that is going to make you fly up the hills at a lightweight 1.785 kg. |
Versatility Versatile by design, Kaius comes with all you would expect from a high-end gravel race bike. It can fit 1x and 2x drivetrains, tires up to 44 mm, a dropper post, our new MTT Suspensions Stem, and top tube bolt-on bags. |
Technologia
| ACE+ |
Technologia Accelerated Composites Evolution (ACE+)ACE + Działa na tysiącach wirtualnych prototypów, wykorzystując sztywność, wagę i |
| ICS |
Integrated Cockpit SystemTechniczne dopracowanie oraz estetyczna prostota zintegrowanego kokpitu ICS pokazują, czym są szwajcarska inżynieria i design. Kable są na swoim miejscu – poza zasięgiem wzroku. Więcej |
Dane techniczne
-
Rama
Premium Carbon
-
Widelec
Kaius 01 Premium Carbon with Aerocore Design ICS Technology, Stealth Cable Routing Integrated Aerocore Bottle Cages Stealth Dropout Design TCC Race Compliance Level PF86 Bottom Bracket Flat Mount Disc
-
Wspornik siodełka
Kaius 01 Premium Carbon ICS Technology, Stealth Cable Routing TCC Race Compliance Level Stealth Dropout Design Flat Mount Disc 12x100mm Thru-Axle
-
Kierownica
BMC RAB 02 Ergo Top Shape Compact Bend
-
Mostek
BMC ICS2 – Integrated Cockpit Design
-
Siodełko
Fizik Vento Argo R5
-
Biegi
2 x 12
-
Korba
SRAM RIVAL AXS WIDE 43-30T
-
Kaseta
SRAM RIVAL AXS XG-1250 10-36T
-
Łańcuch
SRAM FORCE 12
-
Przerzutka przód
SRAM RIVAL eTap AXS
-
Przerzutka tył
SRAM RIVAL eTap AXS
-
Manetki
SRAM RIVAL eTap AXS HRD
-
Hamulce
SRAM Red eTap AXS HRD, tarcze Centerline X (160/160)
-
Obręcze
CRD-400 Carbon, Tubeless Ready, 40mm
-
Piasty
CRD-400
-
Opony
Pirelli Cinturato Gravel H, 40mm
-
Rozmiary
47, 51, 54, 56, 58, 61
-
Maks. rozmiar opony
44mm (Measured Width)
| Size | 47 | 51 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Rider Height CM | <166 | 166-174 | 172-180 | 178-186 | 184-192 | >190 |
| Stack MM | 510 | 530 | 550 | 570 | 595 | 620 |
| Reach MM (reach) | 390 | 397 | 401 | 405 | 410 | 414 |
| Seat Tube MM (st) | 428 | 452 | 468 | 493 | 513 | 533 |
| Top Tube MM (tt) | 546 | 559 | 569 | 579 | 592 | 604 |
| Head Tube MM (ht) | 85 | 106 | 123 | 144 | 170 | 196 |
| Seat Tube Angle (sa) | 73 | 73 | 73 | 73 | 73 | 73 |
| Head Angle (ha) | 71 | 71 | 72 | 72 | 72 | 72 |
| Rear Center MM (rc) | 420 | 420 | 420 | 420 | 420 | 420 |
| Front Center MM (fc) | 596 | 610 | 608 | 619 | 632 | 644 |
| Wheelbase MM (wb) | 1003 | 1017 | 1015 | 1026 | 1039 | 1051 |
| BB Drop MM (drop) | 80 | 80 | 80 | 80 | 80 | 80 |
| Fork Length MM (fl) | 387 | 387 | 387 | 387 | 387 | 387 |
| Fork Rake MM (fr) | 50 | 50 | 45 | 45 | 45 | 45 |
| Trail MM (trail) | 66 | 66 | 68 | 68 | 68 | 68 |
| Crank Length MM | 170 | 170 | 172.5 | 172.5 | 175 | 175 |
| Stem Length MM | 90 | 100 | 100 | 110 | 110 | 120 |
| Stem Angle | -12.5 | -12.5 | -12.5 | -12.5 | -12.5 | -12.5 |
| Bar Width MM | 400 | 420 | 420 | 420 | 420 | 440 |
| Bar Drop MM | 117 | 117 | 117 | 117 | 117 | 117 |
| Bar Reach MM | 77 | 77 | 77 | 77 | 77 | 77 |
| Post Offset MM | 15 | 15 | 15 | 15 | 15 | 15 |
| Standover Height mm | 684 | 722 | 756 | 780 | 798 | 818 |
| Seatpost Length MM | 281.5 | 321.5 | 361.5 | 361.5 | 401.5 | 401.5 |
