Teammachine SLR
FIVE
| The legendary performance of the Teammachine SLR in a widely accessible package. Designed with TCC Race technology in the Teammachine SLR Carbon frame and fork as well as Stealth Dropouts and internal cable routing, this road bike understands the meaning of high performance. The Teammachine SLR Five is finished with electronic Shimano 105 Di2 shifting, a Mavic Open Disc wheelset, and our proprietary aluminium bar and stem for a stellar ride. |
|
Carbon
Teammachine SLR Carbon
Shimano 12spd
SHIMANO, SM-RT70 Rotors (160/140)
Vittoria Rubino, 25mm
Najbliższy sprzedawca przedstawi Ci ofertę.
Obowiązek informacyjny
Administratorem Twoich danych osobowych jest: Taurus Active sp. z o.o. , NIP 6351864367, Regon 524105331 z siedzibą przy ul. Józefa Wieczorka 11, 43-190 Mikołów, zwanym dalej „Administratorem” . Więcej »
Accelerated Composites Evolution Technology + (ACE+) ACE+ not only generates thousands of virtual frameset prototypes to satisfy Stiffness, Weight and Compliance targets, but now also includes a fourth key factor, Aerodynamics. |
Aerocore Design The superlight carbon cages seamlessly integrate with the reshaped down tube and seat tube, resulting in significant drag reduction when used with bottles. Available as an ugrade on the Teammachine SLR line. |
D-Shape Seatpost The latest evolution of our signature D-Shape seatpost: this optimized design features the minimalist saddle clamp, resulting in lower weight; while still retaining excellent aerodynamic performance and compliance. |
Comfort Is Speed The new Teammachine SLR is more compliant than ever, thanks to the latest evolution of the Tuned Compliance Concept (TCC) technology. Fine tuning of the carbon layups, essential vertical frame and seatpost flex, to improve traction and control, resulting in reduced muscle fatigue. |
Bottom Bracket and Torsional Stiffness Renowned for its power transfer, the new Teammachine SLR goes one step further, with its new down tube shape and optimised carbon layup providing even greater bottom bracket shell support. |
Fork Profile An aerodynamically reshaped fork with stealth dropout design and integrated thru-axle nut show that high technical proficiency can go hand in hand with beautiful, minimalist aesthetics. |
Technologia
| ACE+ |
Technologia przyspieszonej ewolucji kompozytówACE + Działa na tysiącach wirtualnych prototypów, wykorzystując sztywność, wagę i podatność jako kluczowe czynniki wpływające, teraz zawiera również czwarty kluczowy czynnik w – aerodynamikę. Więcej |
| TCC |
Tuned Compliance ConceptWydajność na wysokim poziomie – sztywność tam, gdzie jest to potrzebne, oraz ugięcie w odpowiednich miejscach. |
Dane techniczne
-
Rama
Carbon
-
Rozmiary
47, 51, 54, 56, 58, 61
-
Widelec
Teammachine SLR Carbon; • TCC Race Compliance Level; • Internal Cable Routing; • Flat Mount Disc; • Stealth Dropout Design; • 12x100mm Thru-Axle
-
Biegi
2×12
-
Korba
SHIMANO 50-34T
-
Kaseta
SHIMANO 11-34T
-
Łańcuch
Shimano 12spd
-
Przerzutka przód
SHIMANO Di2
-
Przerzutka tył
SHIMANO Di2
-
Manetki
SHIMANO Di2
-
Hamulce
SHIMANO, SM-RT70 Rotors (160/140)
-
Kierownica
BMC RAB 03, ergo top shape, compact bend
-
Mostek
BMC RSM01
-
Wspornik siodełka
Teammachine SLR Carbon D-Shaped Seatpost; • 15mm Offset
-
Siodełko
Fizik Antares R7
-
Piasty
CL-712 (F)/RXC-1425 (R), Thru Axle
-
Obręcze
Mavic Open Disc
-
Opony
Vittoria Rubino, 25mm
-
Maks. rozmiar opony
30 mm
| Size | 47 | 51 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Rider Height CM | <166 | 166-174 | 172-180 | 178-186 | 184-192 | >190 |
| Stack MM | 506 | 530 | 550 | 565 | 584 | 608 |
| Reach MM (reach) | 367 | 377 | 386 | 392 | 401 | 409 |
| Seat Tube MM (st) | 423 | 468 | 504 | 524 | 545 | 574 |
| Top Tube MM (tt) | 517 | 534 | 549 | 559 | 574 | 589 |
| Head Tube MM (ht) | 110 | 130 | 145 | 165 | 184 | 210 |
| Seat Tube Angle (sa) | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 |
| Head Angle (ha) | 71.5 | 71.5 | 72.3 | 72.3 | 72.3 | 72.3 |
| Rear Center MM (rc) | 410 | 410 | 410 | 410 | 410 | 410 |
| Front Center MM (fc) | 568 | 586 | 589 | 599 | 614 | 630 |
| Wheelbase MM (wb) | 968 | 986 | 989 | 1000 | 1015 | 1030 |
| BB Drop MM (drop) | 69 | 69 | 69 | 69 | 69 | 69 |
| Fork Length MM (fl) | 368 | 368 | 368 | 368 | 368 | 368 |
| Fork Rake MM (fr) | 48 | 48 | 43 | 43 | 43 | 43 |
| Trail MM (trail) | 63 | 63 | 63 | 63 | 63 | 63 |
| Crank Length MM | 170 | 170 | 172.5 | 172.5 | 175 | 175 |
| Stem Length MM | 90 | 90 | 100 | 110 | 110 | 120 |
| Stem Angle | ±8 | ±8 | ±8 | ±8 | ±8 | ±8 |
| Bar Width MM | 400 | 420 | 420 | 420 | 420 | 440 |
| Bar Drop MM | 125 | 125 | 125 | 125 | 125 | 125 |
| Bar Reach MM | 70 | 70 | 70 | 70 | 70 | 70 |
| Post Offset MM | 15 | 15 | 15 | 15 | 15 | 15 |
| Standover Height mm | 717 | 752 | 779 | 797 | 817 | 843 |
| Seatpost Length MM | 330 | 380 | 380 | 380 | 380 | 380 |
